Manual Transfer Switch body SIRCO M I-0-II 4P 63A
Mfr. Part No.:
22304006
APT Stock No.:
SO-22304006
Brand:
SOCOMEC
In Stock: available
Need additional quantities?
Contact us for estimated lead timeSubtotal (1 unit)**
GHS 1,657.50
(Exc. VAT)
GHS 2,020.49
(Inc. VAT)
Available For Order
* Delivery dates may change based on your quantity and address.
Shipping & Policy
Payment Methods:
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Secured breaking
Modular device
Improved on-load switching
Description
SIRCO M are manually operated 3 or 4 pole modular transfer switches with positive break indication. They provide on-load transfer between two sources for any low voltage power circuit, as well as safety isolation. Other applications include source inversion (e.g. to change the direction of a motor) or grounding/earthing.
Documents
Shipping & Policy
Payment Methods:
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Specifications
| TECHNICAL CHARACTERISTICS | |
|---|---|
| Length of the product unit [mm] | 76 |
| Width of the product unit [mm] | 105 |
| Depth of the product unit [mm] | 89 |
| Weight [kg] | 0.85 |
| Number of poles | 4 |
| Rated current [A] | 63 |
| Frame size | M2 |
| CLASSIFICATION | |
|---|---|
| UNSPSC | 39122205 |
| ETIM Class | EC000216 |
| IGCC | 5177 |
