CYLINDER BORE 40 STROKE 250MM 1/4 SHAFT 16MM
Mfr. Part No.:
63MP2C040A0250
APT Stock No.:
CMZ-63MP2C040A0250
Brand:
Camozzi
Back Order
Need more stock?
Contact us for Est. Lead TimeSubtotal (1 unit)**
GHS 2,568.90
(Exc. VAT)
GHS 3,131.49
(Inc. VAT)
Available For Order
* Delivery dates may change based on your quantity and address.
Shipping & Policy
Payment Methods:

Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Description
The Series 63 pneumatic cylinders have been developed to guarantee high performance and versatility. Thanks to a new system of adjustable pneumatic cushioning, the cylinders can always guarantee the best regulation whilst significantly reducing noise caused by the impact of the piston on the end block. Besides the standard version, which can be used in many sectors, specific solutions have been developed for applications such as food processing, agriculture, in tensioning, dosing systems and dancer arms for winding applications. There are also versions for demanding application environments, capable of withstanding extreme temperatures, corrosive atmospheres etc.
Documents
Shipping & Policy
Payment Methods:

Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Specifications
Main Specs | |
---|---|
OPERATION | Double-acting |
ROD VERSIONS | Male rod thread |
NAME OF SERIES | 63 |
STROKE | 250 |
CONSTRUCTION | Standard with rod nut |
CONSTRUCTION | Profile |
VERSION | Standard, magnetic |
CUSHIONING | Cushioning on both sides |
BORE | 40 |
TEMPERATURE RANGE [°C] | From 80 to -20 |
General Specs for Cylinders ISO 15552 | |
---|---|
Type of construction | profile (with screws) and round tube (with tie-rods) |
Design | ISO 15552 |
Operation | single and double-acting |
Type of mounting | with front / rear flange, foot mounting, with front / rear / centre / swivel trunnion |
Stroking (min - max) | 10 ÷ 2500 mm |
Operating temperature | standard and low friction: 0°C ÷ 80°C (with dry air -20°C) high temperatures (version W): 0°C ÷ 150°C (with dry air -20°C) low temperatures (version Z): -40°C ÷ 60°C (with dry air -40°C) low temperatures (version Y): -50°C ÷ 60°C (with dry air -50°C) |
