fiber converter MM/LC 2CH 100Mb - for severe environment

Mfr. Part No.:

BMXNRP0200C

APT Stock No.:

SE-BMXNRP0200C

Brand:

Schneider Electric

Currently Unavailable – Back Order Required

Get a Quote

Available For Back Order

Out of stock? No worries! You can back order this product.
To request a back order:

  • Tap the Request Back Order button below
  • Fill out the form with your Name, Email, Phone, and Company

Our team will review your request and contact you with availability and lead time.

* Delivery dates may change based on your quantity and address.

Shipping & Policy

Payment Methods:

Momo Page imagemastercardvise

Shipping Cost:

Contact the supplier about freight and estimated delivery time.

Secure payments:

Every payment you make on aptghana.com is protected by the platform.

Return policy

Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.

Cost-effective modernization and migration

Reduce time to market

Process efficiency

Easy Maintenance

Description

"This fiber converter module is part of the Modicon X80 range, an offer of common input/output for Modicon M340 and Modicon M580." "This fiber optic repeater is equipped with 2 RJ45 EtherNet ports and 2 fiber optic Ethernet ports." "Thanks to a protective coating on its circuit board, this product can be used in harsh environments with a temperature range from -25°C to +60°C/-13°F to 140°F." "Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs." "Its casing provides IP20 protection of the electronics." "This module has a grey color, a weight of 0.203kg and dimensions of 32x100x86mm." "This product meets the needs of our customers from Smart Infrastructure, Water and Waste Water, Consumer Packaged Goods, Mining Minerals Metals, Data centers and Power generation." "This product complies with CE, UL, CSA, RCM, and EAC standards and is certified for Power Generation, Merchant Navy, Railway and Hazardous areas applications." "The product must be installed on the rack and fixed with 2 screws." "Modicon X80 consists in a compatible modules common platform that reduce maintenance and training costs with same spare parts in stock, and unique training for different Programmable Automation Controllers (PAC)." "Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs."

Specifications

Main
Range of product
Modicon X80
Product or component type
Fibre optic repeater
Optic fiber type
Multi mode
Complementary
Rated voltage
24 V
Current consumption
140 mA typical
200 mA maximum
Function available
Hot swap
Number of port
2 RJ45 with 100BASE-TX port Ethernet conforming to IEEE 802.3u
2 fiber optic with 100BASE-FX port Ethernet conforming to IEEE 802.3u
Local signalling
1 LED (green) for power supply status
1 LED (red) for error condition (ERR)
2 LEDs (green) for link status
2 LEDs (green) for fiber port state and activity
Wavelength
1310 nm

Presentation

Presentation


1 : Model number

2 : LED display panel

3 : Optical port with SFP transceiver for LC-type connector

4 : RJ45 Ethernet port

5 : LNK and ACT LED indicators on the RJ45 Ethernet port


Dimensions Drawings

Modules Mounted on Racks
Dimensions


(1) With removable terminal block (cage, screw or spring).

(2) With FCN connector.

(3) On AM1 ED rail: 35 mm wide, 15 mm deep. Only possible with BMXXBP0400/0400H/0600/0600H/0800/0800H rack.

Rack references

a in mm

a in in.

BMXXBP0400 and BMXXBP0400H

242.4

09.54

BMXXBP0600 and BMXXBP0600H

307.6

12.11

BMXXBP0800 and BMXXBP0800H

372.8

14.68

BMXXBP1200 and BMXXBP1200H

503.2

19.81


,
Mechanical Specifications
Dimensions


1 : Backplane

2 : Module

3 : Cable connections
