Name: IMDIFL12H - VIGILOHM 12 CHANNEL FAULT LOCATOR WITH MODBUS HOSPITAL - 110-230VAC - 125/250VDC | SCHNEIDER ELECTRIC
Brand: SCHNEIDER ELECTRIC
SKU: SE-IMDIFL12H
Availability: InStock
Rating: 4.3 (43 reviews)

View allVigilohm Insulation Monitoring Devices

VIGILOHM 12 CHANNEL FAULT LOCATOR WITH MODBUS HOSPITAL - 110-230VAC - 125/250VDC

Mfr. Part No.:

IMDIFL12H

APT Stock No.:

SE-IMDIFL12H

Brand:

SCHNEIDER ELECTRIC

Currently Unavailable – Back Order Required

Available For Back Order

Out of stock? No worries! You can back order this product.
To request a back order:

Tap the Request Back Order button below
Fill out the form with your Name, Email, Phone, and Company

Our team will review your request and contact you with availability and lead time.

* Delivery dates may change based on your quantity and address.

Shipping & Policy

Payment Methods:

Shipping Cost:

Contact the supplier about freight and estimated delivery time.

Secure payments:

Every payment you make on aptghana.com is protected by the platform.

Return policy

Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.

For medical premises such as operating theaters, intensive care units, recovery rooms

individual threshold per feeder

Alarm per relay or communication port

Fast dedicated commissioning procedure

Description

This device belongs to the Vigilohm range designed to monitor ungrounded/IT electrical networks at feeder level, in accordance to installation and products standards This insulation fault location is only possible when it is associated to IM400 20-H. This device is dedicated to monitoring 12 feeders, AC, DC and ACDC, up to 1000V with the voltage adaptor, IFL12VA1T. It mesures the insulation resistance and leakage capacitance per feeder. Configuration is set from the front of the device, through the HMI screen, or from the communication port. Main settings are related to alarm thresholds, channel naming, toroid type (Vigilohm type or other compatible ones), filtering time. Per feeder, it displays insulation resistance from 100 ohms to 250 kilohms and leakage capacitance from 1 to 15 microfarad. Auto-test starts automatically every 5 hours, and on demand. In case the insulation resistance drops below the set threshold, an alarm is triggered thru the IFL output relay, HMI and communication port. Once no fault is monitored, the alarm is cleared, the alarm relay is back to normal. The device can be supplied by a 110VAC to 440VAC source or a 110VDC to 440VDC, all with a tolérence of plus or minus 15%.

Documents

Shipping & Policy

Payment Methods:

Shipping Cost:

Contact the supplier about freight and estimated delivery time.

Secure payments:

Every payment you make on aptghana.com is protected by the platform.

Return policy

Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.

Compatible products

Functions (1)

Sensors (2)

Specifications

Main
Range	Vigilohm
Device short name	IFL12H
Product or component type	Insulation fault locator
Earthing system	IT
Application	Group II medical premise Healthcare
Network capacitance	Lightly capacitive
Type of network	1P + N
Network rated voltage	0…230 V - DC 0…230 V - AC at 45...65 Hz
Number of channels	12

Complementary
Alarm threshold setting	Alarm: 50...200 kOhm
Type of measurement	Network insulation resistance, range: 200 Ohm...250 kOhm, accuracy: +/- 15 %
Accuracy	+/- 15 %
Channel alarm threshold setting	Alarm threshold: settable per feeder
Configurable filtering time	5 s
Response time	1 s 1/5th of set filtering time
