PRESSURE REGULATOR MC SERIES 1/2
Mfr. Part No.:
MC202-R00
APT Stock No.:
CMZ-MC202-R00
Brand:
Camozzi
Back Order
Need more stock?
Contact us for Est. Lead TimeSubtotal (1 unit)**
GHS 1,118.16
(Exc. VAT)
GHS 1,363.04
(Inc. VAT)
Available For Order
* Delivery dates may change based on your quantity and address.
Shipping & Policy
Payment Methods:
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Description
Series MC pressure regulators are available with ports G1/4, G3/8 and G1/2. Versions with secondary pressure relieving are usually available and all regulators can be panel mounted.
Documents
Shipping & Policy
Payment Methods:
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Secure payments:
Every payment you make on aptghana.com is protected by the platform.
Return policy
Enjoy peace of mind with our 7-day return policy for used items, provided they are returned in their original packaging.
Specifications
| Main Specs | |
|---|---|
| TYPE OF REGULATOR | Without by-pass valve (standard) |
| OPERATING PRESSURE | 0.5 ÷ 10 bar (standard) |
| NAME OF SERIES | MC |
| CONSTRUCTION | Self-relieving (standard) |
| SIZE | G3/8 - G1/2 |
| PRESSURE GAUGE | Without pressure gauge (standard) |
| FUNCTION | REGULATOR |
| PORTS | G1/2 |
| General Specs for Pressure regulators | |
|---|---|
| Construction | modular, compact, diaphragm type |
| Materials | zama, brass, NBR, technopolymer |
| Ports | G1/4 G3/8 G1/2 |
| Weight | kg 0,323 0,644 0,624 |
| Mounting | in-line, wall or panel mounting (in any position) |
| Operating temperature | -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
